| USB Camera Equipment |
- Includes a Complete Color Digital Microscope Camera System.
- Camera is Included! USB Camera for Connection to Computer!
- Reduction Lens System built into the camera. This lens system is important to give a more realistic image that isn’t too magnified.
- Capture Live Full Motion Digital Video!
- Capture Stunning 640×480 and 320×240 Pixel Digital Still Images!
- Simple to Use. Plug Camera into Your Computer’s USB Port, Load the Software, and You’re Taking Images!
- Great for Viewing Specimens and Displaying on a Computer!
- Everything You Need: Microscope, Camera, Easy-to-Use Windows Capture and Editing Software, USB Cable. You Provide Only the Computer.
|
|
| Special Features |
- Includes a Wide Field 10x Eyepiece for viewing without the use of a camera.
|
|
| Eyepieces and Magnification |
- 0.7 – 4.5x Continuous Zoom Objective Range Translates into a Highly Magnified Image on your Monitor!
- The CCD Camera’s Chip Size Affects the Total Magnification. Optional Lens can be used to Increase or Decrease Power to Meet Your Specific Application Needs.
- Total Magnification of a Video Microscopy System depends on the Viewing Monitor Size. For Example, if a 1/4 Inch Wide specimen is Fully Displayed on a 14 Inch Wide Monitor, the Total Viewing Magnification is 14 Inch / 0.25 Inch = 56x. Similarly, an 1/8 Inch specimen would yield 112x.
- We Encourage Customers to Call us to Discuss their Specific Magnification and Viewing Requirements.
|
|
| Illumination |
- Includes Fluorescent Ring Light for Bright and Even Illumination.
|
|
| Focusing and Working Distance |
- Easy Large-Sized Focusing Knobs on Both Sides of Microscope.
- Rack and Pinion Steel Gears for Focus Movement.
- Long Working Distance Design to Allow Room for Your Tools (Distance from Bottom of Lens on Head to Top of Object in Focus). Distance Varies Depending on Zoom Magnification.
|
|
| Frame – Base – Size – Weight |
- Large Flat Base for Maximum Stability.
- Total Maximum Overall Height of Microscope (top of c-mount): 515mm.
|
|
| Included Items |
- Includes C-Mount (CCD Camera Attachment) with 0.5x Reduction Lens.
- Includes Instruction Manual, Lens Cleaning Tissue, Dust Cover, and Spare Fluorescent Ring Light Bulb.
|
|
| Options |
- Optional Bottom Lens to Increase or Decrease Magnification or Change Working Distance.
|
|
| Additional Information |
- Manufactured under ISO: 9001 Standards.
- Protective Molded Styrofoam Container.
- Precision Ground Glass Lens.
- Quality Construction, Metal Frame.
- 220V
- 100% Brand New!
|
|
| Manufacturer’s Warranty |
- 1 YEAR Manufacturer’s Warranty on Microscope and 1 YEAR on Camera!
- The warranty covers manufacturing defects. Abuse or damage due to dropping is not covered.
- If your system needs repair, simply let us know and we will see that it is back in service ASAP.
|
