Product Description
| Specially designed for assembly & inspection in industrial. ‘C’ type clamp fits at the edge of the work table and flexible arm allows full extension and 360 deg swivel around mount axis. Advantage is that it does not use any work space and no drilling on worktable. |
Lens : Dia 150 mm made from fine optical glass
Effective Lens Dia. : 135mm
Magnification : 3.5x
Body Material : Aluminum & Brass.
Body Color : Siemens Grey.
Illumination Type : Top
Illumination : 22W Circular Fluorescent Tube Dia.216mm
Color Temp. of Light : 6500°K
Outer Ring Diameter : 220mm
Working Distance : 220mm
Field of View : 160mm
Maximum Height : 580mm
Vertical Movement : N.A.
Horizontal Movement : 890mm
Rotation : 360°
Lens Tilt : 90°
Stand Type : C Clamp
Base Size (LxBxH) : N.A.
Weight 5.0kgs.
Packing Dim. (cms.) : 68x31x38
